HiPOWER 12V 50Ah LiFePO4 Lithium Ion Battery for UPS Lead Acid Battery Replacement

HiPOWER 12V 50Ah LiFePO4 Lithium Ion Battery for UPS Lead Acid Battery Replacement

Nominal Voltage: 12.8V
Nominal Capacity: 50Ah
Energy: 640Wh
Continuous Working Current: 50A
Peak Working Current: 100A
Cycle Life: 5000Cycles
Dimensions:260x168x209 mm
Weight: 5.6kgs
IP Class: IP65
Warranty: 5 Years

HiPOWER 12V 50Ah LiFePO4 Lithium Ion Battery for UPS Lead Acid Battery Replacement

Specification：

Model	LiFePO4 Battery 12V 50Ah
Nominal Voltage	12.8V
Nominal Capacity	50Ah
Energy	640Wh
Cycle Life	>5000 cycles
Months Self Discharge	<3%
Efficiency of Charge	100% @0.5C
Efficiency of Discharge	96~99% @0.5C
BMS Functions	Over charge, over discharge, over current, short circuit and temperature protection
Charge Voltage	14.4 ± 0.2V
Charge Mode	0.2C to 14.6V, then 14.6V, charge current to 0.02C (CC/CV)
Charge Current	5A
Max. Charge Current	50A
Max Continuous Discharge Current	50A
Peak Discharge Current	100A 1-3S
Discharge Cut-off Voltage	10V±0.5V
Charge Temperature	0 ℃ to 55 ℃ (32F to 131F) @60±25% Relative Humidity
Discharge Temperature	-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity
Storage Temperature	-20 ℃ to 45 ℃ (-4F to 113F) @60±25% Relative Humidity
IP Class	IP65
Housing	ABS Plastic Case
Approx. Dimensions	260x168x209mm
Approx. Weight	5.6kgs (12.35lbs)

Suppport OEM/ ODM Service:

* Customize Battery Size/ Color/ Logo, etc.

* Customize Battery Capacity, Working Current;

* Customize Battery Connector/ Charger

* Customize Bluetooth APP

Lead Acid Replacement.jpg

12V Lithium Battery Performance Curves.JPG

BMS Functions：

HiPOWER BMS.JPG

Battery Structures and Assembly Process：

Battery Structure. Process.JPG

Application Scenarios：

HiPOWER Battery Applications.JPG

Certifications：

HiPOWER Certification.JPG

Shenzhen High Power Battery Technology Company is dedicated to the R&D, manufacturing and sales of motive power systems and energy storage systems as one-stop solutions. With more than 10 years of combined experience in manufacturing renewable energy and battery systems, HiPOWER provides Lithium Batteries covering most daily living and working fields. Our products include two main series, which are

1. Energy Storage Batteries & Systems

LiFePO4 Battery for Lead Acid Replacement

RV/Caravan/Camper/Marine/Solar Battery

Rack-mounted Lifepo4 Battery

Wall-mounted Lifepo4 Battery

All-In-One Energy Storage System

Portable Power Station

Low Voltage Energy Storage System

High Voltage Energy Storage System

Commercial & Industrial ESS

2. Motive Power Batteries

Golf Cart Battery

Floor Cleaner/Scrubber Battery

Forklift Battery

Aerial Work Platform Battery

E-bike Battery

E-scooter/motorcycle/tricycle Battery

Starter Battery

Shenzhen High Power Battery Technology Co., Ltd, is a professional and reliable Hi-tech manufacturer of lithium battery and energy storage products. HiPOWER headquarter located in Shenzhen, owns two factories, one in Shenzhen with area over 7000 m² and more than 200 employees, another one in Huizhou City with area more than 10000 m² and more than 250 employees. HiPOWER owns and operates automatic production lines, a full range of test equipment and an advanced MES that collectively address all aspects of its manufacturing process, from electronics, software design to module assembly, battery assembly as well as initial and final testing.

As a renewable energy innovator, HiPOWER is committed to the mission of achieving energy sustainability while creating a better life for human beings. We have always adhered to the concept of innovation and customer-oriented development, environmental protection and green development. We will continuously enhance our innovation ability, outstanding production capacity and increasingly perfect delivery ability to deepen the cooperation with customers all over the world.
