Lithium Battery Pack 60V 20Ah 59.2V 16S for Electric Scooter Bicycle Motorcycle

Lithium Battery Pack 60V 20Ah 59.2V 16S for Electric Scooter Bicycle Motorcycle

Model: Li-Ion Battery 60V 20Ah
Configuration: 16S8P
Nominal Voltage: 59.2V
Nominal Capacity: 20Ah
Energy: 1184Wh
Charge Voltage: 67.2V
Charge Current: 10A max.
Max. Continuous Working Current: 20A or customized
Peak Discharge Current: 60A
Fit Motor Power: 1000W max.
Dimensions:Customized
Weight: 6.3kgs
Cycle Life: 800 Cycles

Customized Lithium Ion Battery Pack 60V 15Ah 59.2V 16S6P with Charger for Electric Bicycle E-scooter Mobility Motorbike

Specification:

Model	Li-Ion Battery 60V 20Ah
Product Parameters
Battery Cell	Grade A 18650 power cells, Chinese big brands or Samsung, LG
Nominal Voltage	59.2V
Nominal Capacity	20Ah
Energy	1184Wh
Charge Voltage	67.2V
Charge Current	10A (Max.)
Charge Method	CC/CV
Working Voltage Range	48V - 67.2V
Max. Continuous Discharge Current	20A or Customized
Peak Discharge Current	60A
BMS Protections	Over charge, over discharge, over current, short circuit and temperature protection
Housing	PVC Wrapped
Connector & Cables	Customized
Dimension	Customized
Weight (Approx.)	6.3KGS
Charge Temperature	0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity
Discharge Temperature	-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity
Storage Temperature	-20 ℃ to 45 ℃ (-4F to 113F) @60±25% Relative Humidity
Cycle Life	800+ Cycles
Motor Power	1000W Max.
Applications	Electric Scooter, E-bike, E-mobility, etc.

Features of HiPOWER Lithium EV Batteries:
1. Lighter weight, smaller size.
2. Can be customized, install easily.
3. Extremely safe, no explosion, no fire under collision.
4. Strong over-discharge resistance and charge retention.
5. Strong charging acceptance and quick-charging capability.
6. Maintenance-free and no acid or water for maintenance in usage.
7. Large capability and long life for all high power output applications.
8. Environmentally friendly non-toxic, non-contaminating, no rare metal.

9. Low self-discharge and good discharge performance at low temperature.

Factory Lithium Battery Test:

HiPOWER' Battery Packs and Battery Cells are tested before delivery to ensure excellent quality and safety.

Test Item	Test Findings
Over Charge Test	NO FIRE,NO EXPLOSION
Over Discharge Test	NO FIRE,NO EXPLOSION
Drop Impact Test	NO FIRE,NO EXPLOSION,NO LEAKAGE
Short Circuit Test	NO FIRE,NO EXPLOSION
Crush Test	NO FIRE,NO EXPLOSION
High Temperature Test	NO DEFORMATION,NO LEAKAGE
Needle Puncture Test	NO FIRE,NO EXPLOSION
