Nominal Voltage: 38.4V
Nominal Capacity: 100Ah
Energy: 3840Wh
Continuous Working Current: 100 A
Peak Working Current: 300 A
Cycle Life: 5000 Cycles
Dimensions: 520x269x220mm
Weight: 32kgs
IP Class: IP65
Connection in Paralels: Max. 4pcs
Bluetooth: Yes
Warranty: 5 Years
Used to replace lead-acid batteries
Specification:
Model | LiFePO4 Battery 36V 100Ah |
Nominal Voltage | 38.4V |
Nominal Capacity | 100Ah |
Energy | 3840Wh |
Cycle Life | >5000 cycles |
Months Self Discharge | <3% |
Efficiency of Charge | 100% @0.5C |
Efficiency of Discharge | 96~99% @0.5C |
BMS Functions | Over charge, over discharge, over current, short circuit and temperature protection |
Charge Voltage | 42.6-43.8V |
Charge Mode | 0.2C to 43.8V, then 43.8V, charge current to 0.02C (CC/CV) |
Charge Current | 10A |
Max. Charge Current | 100A |
Max Continuous Discharge Current | 100A |
Peak Discharge Current | 300A 1-3S |
Discharge Cut-off Voltage | 30V±0.5V |
Charge Temperature | 0 ℃ to 55 ℃ (32F to 131F) @60±25% Relative Humidity |
Discharge Temperature | -20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity |
Storage Temperature | -20 ℃ to 45 ℃ (-4F to 113F) @60±25% Relative Humidity |
IP Class | IP65 |
Housing | ABS Plastic Case |
Approx. Dimensions | 520x269x220mm |
Approx. Weight | 32kgs |
About this item:
1). HiPOWER 36V LiFePO4 battery adopts Automotive Grade LiFePO4 cells with higher energy density and more stable performance and greater power, maintain the capacity with low self-discharge rate.
2). HiPOWER 36V LiFePO4 battery easy to move and install. Easy to carry and install in any location. It is an ideal choice for outdoor camping power supply and simple indoor installation. It’s very suitable for solar residential, RV, camper, solar and off-grid applications.
3.) HiPOWER 36V LiFePO4 battery is environmentally friendly without acid liquid. Renewable energy, harmless to the environment. Robust ABS casing provides excellent impact resistance and toughness.Lithium-ion batteries are safer than lead-acid batteries, which have no ground-fault protection.
4). HiPOWER 36V LiFePO4 battery has a built-in Battery Management System that can handle battery balance, low and high voltage cut-off and short circuit protection, effectively protecting the lithium-ion cells from being damaged by overcharging or over-discharging, extending battery life.
5). HiPOWER 36V LiFePO4 battery has Bluetooth App which can monitor the real time status of the battery from the Phone at any time.
6). HiPOWER 36V LiFePO4 battery support max. 4pcs connections in parallels.
7). HiPOWER 36V LiFePO4 battery support self-heating functions for optional, which allow charged under -30℃ (22F)
8). HiPOWER 36V LiFePO4 battery can be safe used in many areas: emergency power supply, home energy storage system, lighting, trolling motor, fish finder, wheelchair scooter, lawn mower, golf cart, boat, solar system, UPS backup，portable TV, e-Robot, motorhome/RV camper, Travel/Dump Trailer, electric power wheels car and more.
Support OEM/ ODM Service:
* Customize Battery Size/ Color/ Logo, etc.
* Customize Battery Capacity, Working Current;
* Customize Battery Connector/ Charger
* Customize Bluetooth APP
BMS Functions:
Battery Structure and Assembly Process:
Application Scenarios:
Certifications:
